GYMNASIUM EQUIPMENT
4020-R RADIUS CURTAIN
The 4
020 FOLD-UP GYM CURTAIN
is the most cost effective solution
on the market • The fold up divider curtain offers a great solution for dividing
your space for better utilization by providing years of worry free service.
FEATURES:
• Easy installation
• 1HP electric operation – key switch,
key pad, wireless remote
• Independent cast aluminum drums -
easily adjustable
• 19 oz or 22 oz vinyl lower section and
9oz upper section
• Vinyl coated mesh upper section with
welded seams and fully padded batten –
no exposed hardware
• 2 3/8” diameter centerline continuous
drive shaft for even curtain balance and
load distribution
• Straight or curve design available
• Optional curtain lock safety device
locks drive shaft if speed exceeds 1-1/2”
per second.
The
4040XL TOP ROLL GYM DIVIDER CURTAIN
provides a solution for those facilities with height
clearance issues • This low profile divider curtain is
designed to operate without belts, cables, exposed
wires or guide systems • Fabric rolls within 13.5” of
ceiling overhead for maximum clearance • Innovative and
extremely quiet internal tubular motor with all electrical
components neatly packaged inside the drive tube •
Newly designed expandable roller system • Larger drive
tube with vented ends for cooling of the motors • 19 oz.
or 22 oz. vinyl lower section and 9 oz. vinyl coated mesh
upper section • Curtain has welded seams, fully padded
bottom batten, and no exposed hardware • Mounting
assemblies allow for easy installation and leveling.
INTERNAL MOTOR SYSTEM
• Clean look with no wires or cables
exposed
• Internal driveshaft motors enable
lower power requirement and lower
torque to move with similar speed as
standard external motors
• Standard motors pull 15 amps, ours
only 3.5 amps
• Internal motors allow for larger
variation of building configurations
with space constraints
• Used on Models 4050, 4040XL
DESIGNED CARRIER SYSTEM
• Increased diameter aluminum drive
pipe for speeding up the roll time and
prolonging the vinyl life
• New ball bearing roller assembly
designed with longer rollers to
distribute the vinyl load, reducing stress
on the material
• Hardened steel rollers eliminate dirt
buildup and tracking marks on vinyl that
wood or rubber rollers create
• 13.5” compact profile for height
clearance issues
