HEIGHT ADJUSTERS
Bring all ages into the game and make your facility user friendly to even the youngest players, giving
them the ability to compete at heights that are fair and fun for them • Our height adjusters lower your
backboards to any height between 8’ and 10’ • The goal height indicator is located on the unit for
accurate adjustment • All of our height adjusters feature direct goal attachment to transfer any stress
and load from the goal to the backstop’s structure instead of depending on the backboard for support
• Please note, adding GARED’s height adjuster to an existing basketball structure may affect the court
dimensions.
1130: MANUAL SINGLE POST HEIGHT ADJUSTER SERIES
2 YEAR LIMITED WARRANTY, WEIGHT: 73 LBS, TRUCK, FREIGHT CLASS 70, 24 HOUR SHIP
1170: ELECTRIC SINGLE POST HEIGHT ADJUSTER SERIES
• 1158 Hardwire kit is required for operation, not included in 1170
2 YEAR LIMITED WARRANTY, WEIGHT: 84 LBS, TRUCK, FREIGHT CLASS 70, 24 HOUR SHIP
1140: MANUAL DUAL POST HEIGHT ADJUSTER SERIES
2 YEAR LIMITED WARRANTY, WEIGHT: 73 LBS, TRUCK, FREIGHT CLASS 70, 24 HOUR SHIP
1180: ELECTRIC DUAL POST HEIGHT ADJUSTER SERIES
2 YEAR LIMITED WARRANTY, WEIGHT: 84 LBS, TRUCK, FREIGHT CLASS 70, 24 HOUR SHIP
1179: MANUAL TO ELECTRIC HEIGHT ADJUSTER CONVERSION KIT
Manual height adjusters can be converted to electric by adding a motor kit • This can be done
on location.
UNIQUE FEATURE
Spring activated manual locking mechanism is designed to lock the rod in place eliminating any
“drifting” of the backboard height on all manual height adjusters • (Patent 8043174)
MANUAL AAG ELECTRIC AAG TYPE OF ATTACHMENT
1131
1171
Basic adjust-a-goal (no mounting brackets)
SINGLE POST BACKSTOPS
1132
1172
Single post adjust-a-goal for 6 5/8" diameter single post for rectangular backboard with 63" x 36" board mounting;
includes basic adjust-a-goal and kits 1408 & 4404
1133
1173
Single post adjust-a-goal for 6 5/8" diameter single post for fan-shape backboard with 35" x 20" board mounting;
includes basic adjust-a-goal and kits 1408 & 4405
1134
1174
Single post adjust-a-goal for rectangular backboard with 63" x 36" board mounting, single post other than 6 5/8";
includes basic adjust-a-goal and kit 4404. Does not include aag to post mtg • parts • (for custom size posts)
1135
1175
Single post adjust-a-goal for fan-shape backboard with 35" x 20" board mounting, single post other than 6 5/8";
includes basic adjust-a-goal and kit 4405. Does not include aag to post mtg • parts • (for custom size posts)
DUAL POST BACKSTOPS
1142
1182
Adjust-a-goal for 3 1/2" diameter dual post for rectangular backboard with 63" x 36" board mounting; includes basic
adjust-a-goal and kits 3513 & 4404
1143
1183
Adjust-a-goal for 3 1/2" diameter dual post for rectangular backboard with 35" x 20" board mounting; includes basic
adjust-a-goal and kits 3513 & 4405
1144
1184
Adjust-a-goal for 2 3/8" diameter dual post for rectangular backboard with 63" x 36" board mounting; includes basic
adjust-a-goal and kits 2108 & 4404
1145
1185
Adjust-a-goal for 2 3/8" diameter dual post for rectangular backboard with 35" x 20" board mounting; includes basic
adjust-a-goal and kits 2108 & 4405
WALL MOUNTED BACKSTOPS
1146
1186
Adjust-a-goal for GARED wall mounts for rectangular backboard with 63" x 36" board mounting; includes basic
adjust-a-goal and kits 5741 & 4404
1147
1187
Adjust-a-goal for GARED wall mounts for rectangular backboard with 35" x 20" board mounting; includes basic
adjust-a-goal and kits 5742 & 4405
N0N-STANDARD AND NON-SINGLE POST BACKSTOPS
1148
1188
Adjust-a-goal for rectangular backboard with 63" x 36" board mounting; non-standard non-single post; includes basic
adjust-a-goal and kits 4404
1149
1189
Adjust-a-goal for fan-shape backboard with 35" x 20" board mounting; non-standard non-single post; includes basic
adjust-a-goal and kits 4405
