GYMNASIUM EQUIPMENT
PLAYRX™ SINGLE POST CEILING STRUCTURES PRODUCT GUIDE
MODEL
NUMBER
MODELS
3103/3102/3102HD
MODELS
3105/3104/3104HD
MODELS
3107/3106/3106HD
MODELS
3109/3108/3108HD
MODEL S
3111/3110/3110HD
STRUCTURE
DESIGN
APPLICATION
Best for facilities with
adequate space behind
the backboard to
brace the structure
and no obstructions or
clearance issues in front
of the structure • This
design offers maximum
clearance above the
court.
Great choice for those
facilities with clearance
issues over the court
that will not allow front
fold design, yet offers
adequate space behind
the backstop to allow
rear folding for storage
Best used in facilities
designed without
adequate space behind
the backstop structure
for rear bracing, and
with no clearance issues
over the court for front
bracing to fold forward
and up for storage.
This model is the perfect
solution for the fieldhouse
or gymnasium with large
amounts of equipment,
and limited space behind
the backboard and/or
other conditions that
don’t allow front fold, but
still require folding the
backstop up to a stored
position.
Non-folding design with
ceiling brace for those
projects not requiring
backstops to be moved
and will not allow
bracing to the wall.
BRACE DIR
REAR BRACED
REAR BRACED
FRONT BRACED
SIDE BRACED FRONTCEILINGBRACED
FOLD DIR
FORWARD FOLD
REAR FOLD
FORWARD FOLD
SIDE FOLD
STATIONARY
MAST TYPE
SINGLE
SINGLE
SINGLE
SINGLE
SINGLE
MAXIMUM & MINIMUM HEIGHT RESTRICTIONS BY MODEL
31’ MAX, 18’ MIN
3103
3105
3107
3109
3111
32’ MIN
3102/3102HD
3104/3104HD
3106/3106HD
3108/3108HD
3110/3110HD
MAST CONSTRUCTION BY MODEL
WELDED
3103
3105
3107
3109
3111
CLAMPED
3102, 3102HD
3104/3104HD
3106/3106HD
3108/3108HD
3110/3110HD
MODEL
NUMBER
MODELS
3205/3204/3204HD MODEL 3305
MODEL
3207, 3206, 3206HD
MODEL
3209/3208/3208HD
MODELS
3115/3114/3114HD
STRUCTURE
DESIGN
APPLICATION
A bent single post rear
braced rear folding
design which reduces the
space required behind
the backstop for the
brace.
A compact design that
utilizes a track system
to move the backstop
forward as it is raised up
and back, great for those
facilities lacking space
for a standard backfold
and clearance issues for
a standard front fold
backstop.
A bent single post front
braced forward fold
design which reduces the
space required in front
of the backboard for the
brace.
A bent single post side
braced side folding
design which reduces the
space required to the
side of the backstop for
the brace
Non-folding backstop
design with rear wall
brace for those projects
not requiring backstops
to be moved • Maximum
distance from wall to
face of backboard is 14’.
BRACE DIR
BENT REAR BRACED REAR BRACED BENT FRONT BRACED BENT SIDE BRACED REAR CEILING. REAR
WALL BRACED
FOLD DIR
REAR FOLD
ROLL FOLD
FORWARD FOLD
SIDE FOLD
STATIONARY
MAST TYPE
SINGLE
SINGLE
SINGLE
SINGLE
SINGLE
MAXIMUM & MINIMUM HEIGHT RESTRICTIONS BY MODEL
31’ MAX, 18’ MIN
3205
3305
3207
3209
3115
32’ MIN
3204, 3204HD
3206/3206HD
3208/3208HD
3114/3114HD
MAST CONSTRUCTION BY MODEL
WELDED
3205
3305
3207
3209
3115
CLAMPED
3204, 3204HD
3206/3206HD
3208/3208HD
3114/3114HD
