WHEN CHOOSING THE RIGHT WALL MOUNT FOR YOUR FACILITY THERE ARE
SEVERAL FACTORS TO CONSIDER INCLUDING: pre-existing structures or equipment, facility
gymnasium space, condition of facility walls and budgetary constraints. Our telescopic, modular design
allows installation ease and “quick ship” policy. GARED offers a full line of basketball wall mounts to
customize your space for an optimal and safe play environment.
THREE-POINT WALL MOUNT
GARED’S THREE-POINT WALL MOUNT SYSTEM provides the strongest wall mount
structure available for facilities with budget constraints • Incorporates direct-goal attachment
that transfers the load of heavy play through the backboard to the structure • 5/0 upper safety
chains with heavy malleable turnbuckles provide additional support • Telescopic design allows
for complete adjustability and ease of installation • Structural wood mounting pads included •
Mounting hardware provided by others • Board and goal are not included unless wall mount
package is purchased • Not compatible with 60” front mount or rear mount backboards • Height
adjuster is optional.
2350 SERIES: THREE POINT STATIONARY WALL MOUNT SERIES
WEIGHT: VARIES, TRUCK, FREIGHT CLASS 70, 48 HOUR SHIP
• Stationary non-folding unit
• Standard extension length available: 2’ - 12’
2350-3040
2300-3044
2500-4064 2400-9124
FOUR-POINT WALL MOUNT SERIES
GARED FOUR-POINT WALL MOUNT SYSTEMS incorporate four point attachment
for backboards with 36” x 63” or 20” x 35” mounting centers • 5/0 upper safety chains with
heavy malleable turnbuckles provide additional support • Telescopic design allows for complete
adjustability and ease of installation • Structural wood mounting pads included • Mounting
hardware provided by others • Board and goal are not included unless wall mount package is
purchased • Not compatible with 60” front mount backboards • Height adjuster is optional.
2300 SERIES: FOUR-POINT STATIONARY WALL MOUNT SERIES
WEIGHT: VARIES, TRUCK, FREIGHT CLASS 70, 48 HOUR SHIP
• Stationary non-folding unit
• Offers the ability to mount around any obstructions
• Offers a direct goal attachment when height adjuster is purchased
• Standard extension length available: 2’-12’
• Custom extension lengths of 13’-16’ available - allow 4-6 weeks for delivery.
2400 SERIES: FOUR-POINT FOLD UP WALL MOUNT SERIES
WEIGHT: VARIES, TRUCK, FREIGHT CLASS 70, 48 HOUR SHIP
• Stores in fold-up vertical, compact position against wall to prevent
interference with other court activities.
• In play position, unit locks into stationary 4 point position
• Includes manual winch with crank handle; electric hoist and safstop are optional
• Offers a direct goal attachment when height adjuster is purchased
• Standard extension length available: 4’-12’.
2500 SERIES: FOUR-POINT SIDE FOLD
WALL MOUNT SERIES
WEIGHT: VARIES, TRUCK, FREIGHT CLASS 70,
48 HOUR SHIP
• Stores in side fold, horizontal position against wall to
prevent interference with other court activities.
• In play position, unit locks into stationary four point
position
• Allow 14”-18” between wall mount in stored position
and wall, depending on extension length.
• Offers a direct goal attachment when height adjuster is
purchased
• Standard extension length available: 4’-12’
• Electric operation (Model 2500-E) is available as option
• Custom extension lengths of 13’-16’ available - allow 4-6
weeks for delivery.
FIBA (Fédération Internationale de Basketball) hereby declares, by means of certification, that WALL MOUNTED MODELS
2300-9124; 2400-9124; 2500-9124; 2500-1416 fulfills the Competition Level II and WALL MOUNTED MODEL S 2300;
2400 AND 2500 fulfills the Competition Level III standards specified in the latest edition of the Equipment & Venue Approval
Programme and GARED is therefore qualified as an Official Technical Partner. (Contract Number: P04-2015)
2500-3040
