GYMNASIUM EQUIPMENT
MODEL 4080BL BOTTOM LIFT MULTI SPORT CAGE
and
4081BL BOTTOM LIFT BATTING CAGE
are electrically operated sports cages that
suspend from the ceiling • The bottom of the cage netting is automatically lifted to the top frame eliminating the need to manually drape the net over the frame
before lifting • Nylon straps hold the top frame at a preset height above the floor during use • Double cable spools uniformly pull up each side of the lower cage
batten frame to within 1’- 9” of the structure.
CAGE
MODEL
TYPE OF
CAGE
SIZE
NET
MODEL NET SIZE
MESH SIZE
MESH
COLOR
4080BL-70 Multi-Sport
10’H x 12’W x 70’L 4087
12’H x 12’W x 70’L
3/4” Square
Black
4081BL-70 Batting Cage 10’H x 12’W x 70’L 4089
12’H x 12’W x 70’L
1 3/4” Square Black
4080BL-55 Multi-Sport
10’H x 12’W x 55’L 4086
12’H x 12’W x 55’L
3/4” Square
Black
4081BL-55 Batting Cage 10’H x 12’W x 55’L 4088
12’H x 12’W x 55’L
1 3/4” Square Black
Our
MODEL 4075 INDOOR CEILING SUSPENDED
THROWING CAGE
is a top quality unit for use in facilities
where frequent indoor track and field set-up is required •
This product meets all USTF and NCAA requirements for
indoor throwing cages • The net is constructed of 600lb test
(minimum), #72 knotted nylon.
The
HAMMER THROW DOOR FRAME SYSTEM
is comprised of two vertical frame members hinged at the
truss connection point to allow the frames and wing doors to
fold as a single unit • Frames are 4” square heavy wall tubing,
extended to the floor in the down position to support doors
in the proper position for the event • Frames are folded into
the stored position by means of ¼” galvanized aircraft cable on
each vertical frame using a 3/4 HP double drum electric hoist •
The net is constructed of 600lb test (minimum), #72 knotted
nylon.
The
REAR CAGE FRAME
is constructed of 1.9”O.D. heavy
wall tubing featuring a cross spreader spans the perimeter of
the cage to maintain a 5’ distance required by the NCAA rule •
The frame is raised to the overhead storage position by means
of six 1/8” galvanized aircraft cables routed through swivel
pulleys to a central drive pipe • The drive system is powered by
a 3/4 HP electric motor • The net is constructed of 600lb test
(minimum), #72 knotted nylon.
