21 / 112
Our
CLIMBING ROPES
are available in three different
materials with a variety of options for ends, knots, accessories and
attachment methods • Standard lengths are 18’ with custom lengths
also available.
CLIMBING
ROPE MODEL
ROPE
MATERIAL
ROPE ENDING
103MB
Manila Rope
Braided Rope End.
103MPB
Manila Rope
Poly Boot End
103MTK
Manila Rope
Turk Knot End
103MW
Manila Rope
Whipped End
104PB
Polypro Rope
Braided Rope End
104PPPB
Polypro Rope
Poly Boot End
104PTK
Polypro Rope
Turk Knot End
104PW
Polypro Rope
Whipped End
105PPB
Polyplus Rope
Braided Rope End
105PPPB
Polyplus Rope
Poly Boot End
105PTK
Polyplus Rope
Turk Knot End
105PPW
Polyplus Rope
Whipped End
MODEL 109 ADJUSTABLE HEIGHT CHIN UP BAR
is constructed of steel frame rails and welded steel movable
bar structure • Bar is 1” diameter and shall adjust to four predetermined heights using keyhole slots • Includes grey
powdercoat finish.
MODEL 105 PEG BOARDS
are 2” thick hard wood finished with three coats of clear varnish
• Two hand-grip pegs are furnished for each board • Pegboards are available in the following sizes:
Advanced Elementary (24” x 24”), Junior/Senior HS (28” x 28”), Vertical HS (12” x 72”), and High
School/Collegiate (31”x31”)
105
MODEL 108 ARM LADDER
is constructed with 15/16” diameter heavy
wall tubing • Support frame is fastened to 2”x 6” wood boards sealed and
varnished are mounted to the wall on 22” centers • Grid rungs are 1”
diameter steel tubing spaced 8” apart • Includes grey powdercoat finish.
MODEL 106 GRID CLIMBER
is constructed of 15/16” diameter heavy
wall tubing • Support frame is fastened to 2”x 6” wood boards sealed and
varnished that are mounted to the wall on 31 5/16” centers • Grid rungs
are 1” diameter steel tubing • Includes grey powdercoat finish.
MODEL 104 HORIZONTAL LADDER
is constructed of 1 5/8”
diameter heavy wall tubing • Support frame is fastened to 2”x 6” wood
boards sealed and varnished that are mounted to the wall • Ladder rungs
are 1” diameter steel tubing • Includes grey powdercoat finish.
BALL
BALL
KNOT
TAMBOURINE
ACCESSORIES
CABLE
CLAMPS
109
104
108
106
21
GYMNASIUM EQUIPMENT
1–888–743–8226
