Gared Sports Catalog

GARED PRO S FEATURES

BACKBOARD:

Official size 42” x 72” shatter proof rectangular glass backboard (Model LXP4200) with a welded and reinforced steel frame. 1/2” tempered

glass with fired in target and border for maximum durability. LED perimeter lights, #2137, are sold separately.

GOAL:

Models 3500 and 3500I Master, positive lock breakaway goals come standard with these units for the domestic and international markets respectively.

Model 3500I Master meets all FIBA standards. Other breakaway goals are optional and available upon request.

PADDING:

Durable GARED PRO-MOLD® backboard edge padding comes in a wide variety of colors. Standard color for system padding is royal blue; other

standard colors are available at no additional cost. Custom logos for the front and side pads are available at an additional cost.

BALLAST:

1200 lbs. (544 kgs.) of enclosed ballast concealed in the base of the unit, welded closed.

HEIGHT ADJUSTABLE

: Unique telescoping brace allows for preset heights of 8’, 9’ and 10’. Custom heights are available upon request.

ADJUSTABLE FLOOR PADS:

Two floor pads are encased in steel supports for added stability, and are controlled by a screw-type mechanism that raises the

unit off the wheels and adjusts the unit to exactly 10’ height.

FLOOR ANCHORING SYSTEM:

Floor anchors and locater pins are included as standard. Specify floor type.

FINISH:

The unit is powdercoated white. Other colors are available at additional cost.

SHOT CLOCK & CAMERA SUPPORTS:

Available at a nominal cost. Specify shot clock type.

TRANSPORT & STORAGE:

Folds easily for compact storage with non-marking polyurethane casters for easy transport.

9621: AUTOMATIC FRONT WHEEL LIFT SYSTEM

This optional system is designed to make the basic installation and set up of the

GARED PRO S

effortless. It eliminates the need to adjust the leveling pads by automatically lifting the front wheels

off the ground when the boom is raised to the play position and lower them when the boom is

lowered to the folded or stored position. As the portable is raised, a cam operated mechanism

raises the front wheels off the floor causing the boom to lock in the play position and the base to

rest evenly on the supporting frame. Conversely, when the wheels are in the down position the

portable can be moved around.

9806 QUICK CONNECT™ MOUNTING PLATES

Allows for quick and easy installation and removal of backboard

and goal.

(Patent 7967705, 7794342)

QUICK BOARD PLUMBING ADJUSTMENT

Allows for quick, easy and accurate plumbing of the backboard

for proper play.

SPRING ASSIST OPERATION

Spring design allows backstop to be easily lifted in under 10 seconds.

Additional spring can be easily installed if shot clock is added.

SHIPPED WITH BALLAST

GARED PRO S is shipped with ballast securely enclosed

within a welded basin located in back of portable unit’s base.

PORTABLE BASKETBALL BACKSTOPS

1–888–743–8226
