HOOPMASTER
®
: MOST VERSATILE SPRING BALANCED PORTABLE BASKETBALL
BACKSTOP SYSTEM
This state-of-art portable basketball system uses the GARED tension spring technology for easy use and operation • The maintenance-free tension spring
mechanism has been engineered for balanced and effortless lifting and lowering of the unit and the springs are concealed inside the base for safety and
appearance • The Hoopmaster® is designed for main court play in university, high school and professional arenas • It is ideal for all side court play and it is
approved by FIBA for level 3 international competition • Available in 8’ boom extensions for all levels of play and adjustable at 8’, 9’ and 10’ heights • The
Hoopmaster® comes with an official size (42” x 72”) shatter proof glass backboard, our original PRO-MOLD® backboard padding, and a positive lock
breakaway goal • The base is fully padded on three sides with vinyl covered high density polyurethane foam • The front is similarly padded to a height of 7’.
Boom pad and anchoring system are included with the unit • Shot clock supports are sold separately • Full weight with ballast 2200 lbs. (998 kgs)
•
10 YEAR LIMITED WARRANTY ON ALL PARTS, LIFETIME LIMITED WARRANTY ON BACKBOARD INCLUDED WITH THE UNIT, 5
YEAR LIMITED WARRANTY ON PRO-MOLD® PADS AND 4 YEAR ON BREAKAWAY GOAL.
HOOPMASTER® FEATURES
BACKBOARD:
Official size 42” x 72” tempered glass backboard with a welded reinforced powdercoated steel frame (Model LXP4200). 1/2” tempered glass
with fired in target and border for maximum durability. LED perimeter lights, #2137, are sold separately.
GOAL:
Models 2500 Collegiate and 2500I Tournament, positive lock breakaway goals come standard with these units for the domestic and international
markets, respectively. Other breakaway goals are optional and available upon request.
PADDING:
Durable GARED PRO-MOLD® backboard edge padding comes in a wide variety of colors. Standard color for system padding is royal blue; other standard colors are
available at no additional cost. Custom logos for the front and side pads are available at an additional cost.
BALLAST:
1000 lbs. (455 kgs.) of enclosed ballast concealed in the base of the unit, welded closed.
HEIGHT ADJUSTABLE:
Unique telescoping brace allows for preset heights of 8’, 9’ and 10’. Custom heights are available upon request.
ADJUSTABLE FLOOR PADS:
Two floor pads are encased in steel supports for added stability, and are controlled by a screw-type mechanism that raises the
unit off the wheels and adjusts the unit to exactly 10’ height.
FLOOR ANCHORING SYSTEM:
Floor anchors and locater pins are included as standard. Specify floor type.
FINISH:
The unit is powdercoated white. Other colors are available at additional cost.
TRANSPORT & STORAGE:
Folds easily for compact storage with single non-marking polyurethane casters for easy transport.
9806 QUICK CONNECT™ MOUNTING PLATES
Allows for quick and easy installation and removal of backboard
and goal.
(Patent 7967705, 7794342)
QUICK BOARD PLUMBING ADJUSTMENT
Allows for quick, easy and accurate plumbing of the backboard
for proper play.
SPRING ASSIST OPERATION
Spring design allows backstop to be easily lifted in under 10 seconds.
Additional spring can be easily installed if shot clock is added.
SHIPPED WITH BALLAST
GARED PRO S is shipped with ballast securely enclosed
within a welded basin located in back of portable unit’s base.
9408: GARED HOOPMASTER®8 WITH 8’ BOOM
8’ BOOM FOR (2.45 M) PORTABLE BASKETBALL BACKSTOP
10 YEAR LIMITED WARRANTY ON ALL PARTS, LIFETIME LIMITED WARRANTY
ON BACKBOARD INCLUDED WITH THE UNIT, 5 YEAR LIMITED WARRANTY ON
PRO-MOLD® PADS AND 4 YEAR ON BREAKAWAY GOAL
WEIGHT: 2405 LBS. DEDICATED TRUCK
9405: GARED HOOPMASTER®5 WITH 5’ BOOM
5’ BOOM FOR (1.5 M) PORTABLE BASKETBALL BACKSTOP
10 YEAR LIMITED WARRANTY ON ALL PARTS, LIFETIME LIMITED WARRANTY
ON BACKBOARD INCLUDED WITH THE UNIT, 5 YEAR LIMITED WARRANTY
ON PRO-MOLD® PADS AND 4 YEAR ON BREAKAWAY GOAL
WEIGHT: 2392 LBS. DEDICATED TRUCK
