Technical Specifications
Critical Fall Height and Physical Dimensions
Thickness
Weight (lbs.) Each (Not less than)
Critical Fall Height (ft.)
Pigmented
Carnival & Safari
Pigmented
Carnival & Safari
1”
16
16
2.0
2.0
2-1/2”
25
27
6.0
6.0
3-3/4”
34
N/A
8.0
N/A
4-1/4”
N/A
39
N/A
8.0
2-1/2 & 2-1/8” Polyfoam
27
29
10.0
10.0
Physical Data Test
Characteristic
Test Method
Pigmented Tile
Carnival & Safari Tile
Density
ASTM D297
50 lb./ft3 min.
70 lb./ft3 min.
Tensile Strength*
ASTM D412, DIE C
150 lb./in2 min.
180 lb./in2 min.
Elongation at Break*
ASTM D412, DIE C
50% min.
70% min.
Abrasion Test*
ASTM D3389
Less than 0.010” lost
Less than 0.010” lost
Coefficient of Friction*
ASTM D2047
0.8 min.
0.8 min.
Flammability
ASTM D2859 (Burning Pill Test)
8 of 8 samples passed
8 of 8 samples passed
Wheel Chair Accessibility
ASTM F1951-08
Pass
Pass
Lead Content
US EPAMethod 3052:1996
Pass
Pass
FIFTEENYEAR LIMITEDWARRANTY INFORMATION - Materials, Workmanship, and Performance
Number of years from date of original
installation to date of claim
Percentage of product purchase price
found to be defective or non-compliant
0-6
100%
More than 6, but less than 7
60
%
More than 7, but less than 8
40%
More than 8, but less than 9
30%
More than 9, but less than 10
20%
More than 10, but less than 12
10%
More than 12, but less than 15
5%
Packaging Information
Full Pallet Weight (lbs.)
Thickness
Pieces/Pallet
Pigmented
Carnival & Safari
Pallet Height
Other Packaging Information
1”
120
1,980
1,980
35.00”
Standard Pallet Size: 48”x48”
Empty Pallet Weight: 60 lbs
Standard Pallets in 48’ Van: 20
2-1/2”
100
2,560
2,760
66.00”
3-3/4”
60
2,100
N/A
62.00”
4-1/4”
60
N/A
2,400
68.00”
2-1/8” x 4’ x
6’ (Polyfoam
Sheet)
23
680
680
52.00”
