• Available in 2 sizes:
- 8” x 8” x 17mm for 2-1/2” Tiles
- 8.75” x 8.75” x 19mm for 33/4” and 41/4” tiles
• 15 year warranty
• Recycled rubber and polyurethane composition
• Highly durable
• Enables rooftop installation capabilities
• Eliminates damage to the roofing membrane
• Allows rapid water drainage around each tile
• Ample void under tiles for water drainage flow
NOTE: ONE QUAD BLOK PER TILE IS REQUIRED
Tiles legs mate to cutouts
QuadBlok for 2-1/2” Tile
QuadBlok for 3-3/4” & 4-1/4” Tile
3/8” diameter bead of
E-Grip III Adhesive
Features:
Ideal for playgrounds, rooftops, and patios, our exclusive Quad
Blok™ system offers reliable easy-down/easy-up installations.
Quad Blok connectors are made of high quality, post-consumer
tire rubber and polyurethane. Unlike labor intensive poured-in-
place systems, Quad Blok modular connectors feature precisely
located multiple openings that interface with the corner leg
understructure of PlayGuard tiles. These connectors are quick
and easy to use without adhering to or causing damage to
playground substrates. If an individual tile ever does need
replacement, removing and securing a new tile causes minimal
disruption or downtime.
Quad Blok
TM
Property
Test Method
Typical Result
Density
ASTM D297
45-lbs.
/cu.ft.
3
min.
Tensile Strength
ASTM D412, DIE C 100psi. min.
Elongation
ASTM D412, DIE C 65% min.
Compression
ASTM F36
Recovery
@50psi
15%
80%
@100psi
28%
90%
@200psi
45%
95%
Shore A Hardness
ASTM D2240
50 +/- 5 points
Tear Strength
ADTM D624,
DIE C
30-lbs.f/in
Flexibility
ASTM F147
0-1 Factor
Compression Set B
25% deflection, 22 hrs.
158˚F
ASTM D395
25%
Compression Set (Foam)
50% deflection, 22 hrs.
158˚F
ASTM D3676
20%
