62 PLAY SYSTEMS REVOLUTION™
Designed for Children:
Child Capacity:
Structure Size:
Use Zone:
This playground system design meets the requirements
for access under the Accessibility Guidelines for Play Areas
developed by the Federal Access Board when properly
installed over accessible surfacing.
! WARNING: An impact absorbing
safety surface is required under and
around all playground equipment.
PC-4765-RV5
5 to 12 years
142 to 146 children
58’ x 37’ (17.7m x 11.3m)
70’ x 49’ (21.3m x 14.9m)
PLAY
Front Perspective
Back Perspective
Top View
Gyro-Capsule
Spinner
Gyro-Capsule
Spinner Tri-Ring
Link
Tri-Ring Link
Addition
Cube Rope
Net Hub
2-Section
Lunar Climber
2-Section
Lunar Climber
Warp Rung
Wall Climber
(7)
Tri
Pads Tri
Pad Orbital
Ring
Hub
Launch
Pad
Launch
Pad
Launch
Pad
Launch
Pad
Launch
Pad
Matrix Steel Net Wall
Twist Link
Launch
Pad
Rope
Core
Net
Hub
Launch
Pad
Launch
Pad
Wheel Traverse
Matrix Rope
Net Wall
Launch
Pad
Launch
Pad
Tri-Step
Traverse
Tri-Ring
Hub
Arch Loop
Traverse
Angled Rung
Climber
Angled Lunar
Climber
Launch
Pad
3-Tier
Launch
Pad
Climber
3-Tier Launch
Pad Climber
3-Tier Launch
Pad Climber
(2) Arched Lunar
Climbers
(3) Tri Pads
3-Tier
Launch
Pad
Climber
4-Tier
Launch
Pad
Climber
(2) 4-Tier Launch
Pad Climber
Curved
Boardwalk
Track Ride
Tyke Tipper
20’ Sail
Shade
Canopy
20’ Sail
Shade
Canopy
