60 PLAY SYSTEMS REVOLUTION™
Designed for Children:
Child Capacity:
Structure Size:
Use Zone:
This playground system design meets the requirements
for access under the Accessibility Guidelines for Play Areas
developed by the Federal Access Board when properly
installed over accessible surfacing.
! WARNING: An impact absorbing
safety surface is required under and
around all playground equipment.
PC-4285-RV5
5 to 12 years
93 to 97 children
46’ x 24’ (14m x 7.3m)
58’ x 36’ (17.7m x 11m)
PLAY
Front Perspective
Back Perspective
Top View
Arch Slide
Tri-Ring Link
Tri-Ring Link
Addition
Cross Loop
Dual Arch
Rope Net
Climber
Slither Climber
(2)
Tri Pads
Tri
Pad
Tri
Pad
4-Tier
Launch
Pad
Climber
4-Tier
Launch
Pad
Climber
3-Tier Launch
Pad Climber
3-Tier Launch
Pad Climber
3-Tier Launch
Pad Climber
Freeform
Climber
Twist Link
Angled Rung
Climber
Arch Loop
Traverse
3-Tier Launch
Pad Climber
Wheel
Traverse
Matrix Rope
Net Wall
Warp
Rung
Wall
Climber
Launch Pad
Launch Pad
Launch Pad
Launch Pad
Tri-Ring
Hub
Angled
Lunar
Climber
Angled
Wave Rung
Climber
Orbital
Ring
Hub
