Playcraft Systems Manufactured by Krauss Craft, Inc.
39 PLAY SYSTEMS
ROUND-3.5 MODULAR
PC-8612-R35
PC-5186-R35
These playground system designs meets the requirements
for access under the Accessibility Guidelines for Play Areas
developed by the Federal Access Board when properly
installed over accessible surfacing.
!
WARNING:
An impact absorbing
safety surface is required under and
around all playground equipment.
PLAY
PC-5775-R35
36”
Playseat
(below)
48”
48”
54”
60”
66”
72”
72”
Observation Deck
w/ Telescope
(above)
Pilot Panel
(above)
Maze Panel
(below)
Hex
Roof
Gadget
Panel
Quarter
Turn
Slide
Shingled
Pyramid
Roof
Transfer
Station
Bedrock
Climber
Inclined
Arch
Bridge
Snake
Climber
Wheel on
Post
(48” deck)
Track
Climber
Spiral
Step
Climber
Memory
Panel
(above)
24" Poly
Wall
(below)
Store
Panel
(below)
Spiral
Slide
72”
72”
72”
48”
72”
72”
Spiral Slide
Transfer
Station
Open Store Panel
w/ Lily Pad Seat
(below)
Balcony Deck
w/ Wheel
(above)
Gear Panel
(below)
Spiral Step
Climber
Spiral
Climber
(2) Shingled
Pyramid
Roofs
Arch
Bridge
24” Rise
Stairs
Belt
Bridge
Dual Express
Slide
Deep Rung
Arch Climber
Twister
Slide
Twister
Slide
Tic-Tac-Toe
Panel
Poly Double
Slide
Quarter
Turn
Slide
Transfer
Station
Wheel on Post
w/ Lily Pad
Seat
Easy
Access
Stairs
Shingled
Gable
Roof
S-Shaped
Crawl Tube w/
View Ports
Spiral
Step
Climber
36”
36”
Shingled
Gable
Roof
Designed for Children:
Child Capacity:
Structure Size:
Use Zone:
Designed for Children:
Child Capacity:
Structure Size:
Use Zone:
Designed for Children:
Child Capacity:
Structure Size:
Use Zone:
2 to 12 years
79 to 83 children
26’ x 16’ (7.9m x 4.9m)
38’ x 28’ (11.6m x 8.5m)
2 to 5 years
37 to 41 children
21’ x 13’ (6.4m x 4m)
33’ x 25’ (10.1m x 7.6m)
5 to 12 years
73 to 77 children
29’ x 25’ (8.8m x 7.6m)
41’ x 37’ (12.5m x 11.3m)
