Playcraft Systems Manufactured by Krauss Craft, Inc.
35
Designed for Children:
Child Capacity:
Structure Size:
Use Zone:
PLAY SYSTEMS
ROUND-3.5 MODULAR
This playground system design meets the requirements
for access under the Accessibility Guidelines for Play Areas
developed by the Federal Access Board when properly
installed over accessible surfacing.
!
WARNING:
An impact absorbing
safety surface is required under and
around all playground equipment.
PC-8415-R35
2 to 12 years
143 to 147 children
39’ x 26’ (12m x 7.9m)
51’ x 38’ (15.5m x 11.8m)
PLAY
Front Perspective
Back Perspective
Top View
20’ Sail
Shade Canopy
Poly
Straight
Slide
Poly
Wave
Slide
Boulder
Stack
Climber
Maze
Panel
Pal
Inclined
Arch
Bridge
Poly
Double
Slide
Drum
Panel
(below)
Store
Panel
(below)
Bell
Panel
Pal
Spiral
Step
Filler
Chime
Panel
Seek
Panel
Bell Panel
(42” deck)
Hourglass
Panel
Spiral
Slide
Clubhouse
(below)
Bedrock
Climber
Arch
Bridge
Playseat
(below)
Wall w/
Telescope
36” Disc
Climber
36” Disc
Climber
Twister
Slide
Belt
Bridge
36” Disc
Climber
48” Disc
Climber
48” Disc
Climber
48” Disc
Climber
Track
Climber
Transfer
Station
48”
48”
48”
72”
36”
36”
36”
42”
36”
48”
20’ Sail
Shade Canopy
