24 PLAY SYSTEMS ROUND-5 MODULAR
Designed for Children:
Child Capacity:
Structure Size:
Use Zone:
This playground system design meets the requirements
for access under the Accessibility Guidelines for Play Areas
developed by the Federal Access Board when properly
installed over accessible surfacing.
! WARNING: An impact absorbing
safety surface is required under and
around all playground equipment.
PC-8285-R5
5 to 12 years
178 to 182 children
37’ x 25’ (11.3m x 7.6m)
49’ x 37’ (14.9m x 11.3m)
PLAY
Front Perspective
Back Perspective
Top View Upper Level
3-Rung
End Access
Ladder
90° Loop
Traverse
Inclined
Arch
Bridge
Poly Double
Wave Slide
w/ Hood Store Panel
w/ Lily Pad
Seat (below)
Inclined
Geo-Wave
Link
Orbit
Wheel
Memory
Panel Gear
Panel
59” Steel
Wall
Bedrock
Climber
59” Steel
Wall
Hourglass
Panel
36”
24”
48”
72”
72”
36” 36”
36”
36”
Chain
Net
Climber
24” Rise
Stairs
Vertical
Rock
Climber
Playseat
(below)
Erector Rock
Climber w/
Curved Rung
Ladder
Bubble
Mirror
Panel
Gyro-Pod
Spinner
72” Disc
Climber
36” Disc
Climber
Access Walls
Crunch
Handle Boogie
Board
12” Rise
Stair
Transfer
Station
Spiral
Tube
Slide
Spiral
Step
Climber
Pinball
Panel
Window
Panel
Labyrinth
Panel
Window
Panel
Center
Access
Climber
Poly Wall
Climber
Extended
Hex Roof
Spiral
Tube
Slide
96”
96” 96”
96” (2)
