5100 OMNISTEEL™ SCHOLASTIC TELESCOPIC SYSTEM
Steel competition volleyball system offers a traditional design with unmatched strength for all levels of volleyball play • Durable 3” O.D.
telescopic steel posts for competition regulation games provide unyielding strength and support • Sleek black powdercoated finish •
Features hassle-free net height adjustment with our pin-lock mechanism designed to quickly set the net to men’s, women’s, and juniors
heights • Engraved markings on telescopic post indicate height • Internal spring system keeps telescopic post from free falling inside
the base post when the pin lock is removed • Net Glide System at the top of the post easily glides the net cable over the post to the
ratchet winch for tensioning • Meets USVBA, NCAA, and NFHS competition specifications,
LIMITED LIFETIME WARRANTY ON
UPRIGHTS AND 3 YEAR LIMITED WARRANTY ON WINCH ASSEMBLY, FLOOR SLEEVES AND COVERS
5100: OMNISTEEL™ ONE-COURT VOLLEYBALL SYSTEM
WEIGHT: 186 LBS (85 KGS.), TRUCK, FREIGHT CLASS 100, 48 HOUR SHIP
ONE-COURT SYSTEM INCLUDES:
• (1) 3” O.D. Scholastic upright
• (1) 3” O.D. Scholastic upright with winch
• (2) 3” Floor sleeves
• (2) Swivel brass or chrome cover plates
• (1) Competition net
• (1) Pair of antennas and sideline markers
• (2) Upright safety pads
5105: OMNISTEEL™ ONE-COURT VOLLEYBALL SYSTEM
LESS FLOOR SLEEVES AND COVER PLATES
WEIGHT: 168 LBS (76 KGS.), TRUCK, FREIGHT CLASS 100, 48 HOUR SHIP
5102: OMNISTEEL™ TWO-COURT SYSTEM
WEIGHT: 272 LBS (124 KGS.), TRUCK, FREIGHT CLASS 100, 48 HOUR SHIP
5183: OMNISTEEL™ THREE-COURT SYSTEM
WEIGHT: 246 LBS (112 KGS.), TRUCK, FREIGHT CLASS 100, 48 HOUR SHIP
5100 SYSTEM FEATURES
1. Engraved height settings on each post
2. Stop pin for fast adjustment of net height
3. Cable holds pin securely to post
4. Heavy duty ratchet winch for smooth and easy net tension adjustment
5. Winch handle that folds for added safety
6. Internal spring assist for easy net height adjustment
7. 3” O.D. Steel uprights
8. Adjustable foot pad for achieving precise height requirements
HASSLE FREE NET HEIGHT
ADJUSTMENT PIN LOCK
SYSTEM
RATCHET WINCH WITH
FOLDING HANDLE
1
2
3
4
5
6
7
8
