ARE YOU BUILDING A BASKETBALL COURT, BUT UNSURE WHERE TO BEGIN?
When searching for an outdoor system, consider play environment, usage, weather elements, and budgetary
concerns. GARED makes it easy by offering three levels of outdoor posts and packages – economy,
standard-duty, and heavy-duty – so you can choose the outdoor system that is most suitable for your
application.
OUTDOOR POSTS
Build your court by first choosing an appropriate backstop - GARED OUTDOOR POSTS are offered in several styles, sizes and safe play zones to fit your
facility’s needs • Posts are formed from heavy wall galvanized steel for superior protection against weather elements • Each post is approximately 13’ tall, with
3’ to be installed in a 4’ x 2’ concrete footing to ensure long-lasting post stability • 5-9/16” and 6-5/8” O.D. posts are comprised of Schedule 40 steel, providing
unmatched strength and durability to the units • All posts contain a backboard mounting plate welded to post end for hassle-free attachment to most backboards •
Powdercoated posts available – please call for quotation • PPWR post padding is optional and recommended.
GN/GNA SERIES: GOOSENECK POSTS
SEE CHART FOR WEIGHTS, TRUCK, FREIGHT CLASS 50, 24 HOUR SHIP
• Round post with traditional gooseneck design
• Fixed height
• Available with or without backboard braces
• Braced units include a V-brace with attachment hardware to eliminate backboard vibration
GN/GNA SERIES: GOOSENECK POSTS
MODEL # DESCRIPTION
POST
O.D. EXT
ADJUST-
ABLE?
MOUNTING
TYPE WT
LTD.
WARRANTY
GNA35 Unbraced Gooseneck 3 1/2” 3’ No Front Mount 72 10 Year
GNA35R Unbraced Gooseneck 3 1/2” 3’ No Rear-Mount 72 10 Year
GN35 Braced Gooseneck 3 1/2” 3’ No Front Mount 78 10 Year
GN35R Braced Gooseneck 3 1/2” 3’ No Rear-Mount 78 10 Year
GNA45 Unbraced Gooseneck 4 1/2” 4’ No Front Mount 128 25 Year
GNA45R Unbraced Gooseneck 4 1/2” 4’ No Rear-Mount 128 25 Year
GN45 Braced Gooseneck 4 1/2” 4’ No Front Mount 134 25 Year
GN45R Braced Gooseneck 4 1/2” 4’ No Rear-Mount 134 25 Year
GN455 Braced Gooseneck 4 1/2” 5’ No Front Mount 146 25 Year
GN455R Braced Gooseneck 4 1/2” 5’ No Rear-Mount 146 25 Year
GN60 Braced Gooseneck 5 9/16” 6’ No Front Mount 259 Lifetime
AAB/AABS SERIES: ADJUSTABLE STRAIGHT POSTS
SEE CHART FOR WEIGHTS, TRUCK, FREIGHT CLASS 50, 24 HOUR SHIP
• Straight vertical round post with horizontal extension arm
• Arm is height-adjustable to allow for all-age play settings
• All units include a V-brace with attachment hardware to eliminate backboard vibration
• 5-9/16” and 6-5/8” posts include an additional strut connecting the vertical post to the arm for added rigidity
AAB/AABS SERIES: ADJUSTABLE STRAIGHT POSTS
MODEL # DESCRIPTION
POST
O.D. EXT
ADJUST-
ABLE?
MOUNTING
TYPE WT
LTD.
WARRANTY
AAB35 Straight Post w/ Braced Arm 3 1/2” 3’ Yes Front Mount 91 10 Year
AAB35R Straight Post w/ Braced Arm 3 1/2” 3’ Yes Rear-Mount 91 10 Year
AAB45 Straight Post w/ Braced Arm 4 1/2” 4’ Yes Front Mount 138 25 Year
AAB45R Straight Post w/ Braced Arm 4 1/2” 4’ Yes Rear-Mount 138 25 Year
AABS60 Straight Post w/ Braced & Strutted Arm 5 9/16” 5’ Yes Front Mount 287 Lifetime
AABS65 Straight Post w/ Braced & Strutted Arm 6 5/8” 6’ Yes Front Mount 362 Lifetime
DP35 Double Straight Post w/ Two Arms 3 1/2” Two 3’ No Front Mount 220 10 Year
